Standard Door Technical Specifications


Standard Door Technical Specifications
  • Top Track with Fascia and Slide Guides (except Premium which has a sprung 2 wheel guide)
  • No Soft Close (upgrade now available, check design tool for pricing)
  • Sized to suit an opening height of 2250-2260mm (2275mm if adding soft close)
  • Maximum Opening width (using a single track) 3607mm
  • Available door widths of 610mm (24inch), 764mm (30 inch) and 914mm (36inch)

Door Frame widths and overlaps between front and rear doors:
Generally we recommend that the overlap between front and rear doors is the same as the width of the door frame. We do this for aesthetic reasons only, so the amount of overlap is really your choice. Choose more or less overlap to make standard doors fit smaller or larger openings. You may notice that the door visualizer shows no overlap. This is just due to limitations in the software.

Overlap and door frame widths
Contemporary = 25mm Stanley Steel Frame
Classic: = 25mm Stanley Steel Frame
Kids = 25mm Stanley Steel Frame
Shaker = 75mm Stanely Steel Frame
Premium = 35mm Stanley Steel Frame



Sliding Wardrobe Door Running Gear Durability
All our sliding wardrobe wheels and guides are cycle tested to 100,000 opening and closing actions in accordance with ANSI BHMA A156.14, This is an American National Standard, created in conjunction with Builders Hardware Manufacturers Association. The reason we test to this standard is because it’s the most rigorous standard in the world, and enables our hardware to be sold to the contract market in the USA, and enables us to confidently guarantee our running gear for 10 years of continuous use. Manufactured in accordance with the original Stanley patents and designs.

Sliding Wardrobe Door Framing
All our standard sized door frames are manufactured from high grade roll formed steel. This ensures a lifelong sturdy frame to your door, and will not be prone to damage or warping like some lower quality chipboard or MDF framed doors. They also have the advantage over wood in that they will not bow over time. All rollforming is done in the UK using original Stanley equipment and designs

Sliding Wardrobe World Top and Bottom Tracks
Top and bottom tracks are also manufactured from high grade roll formed steel, using original Stanley equipment and designs.

Sliding Wardrobe World Mirror and Gloss Glass
High gloss glass panels are lacquered on the reverse face, to provide the highest quality gloss surface panels on the market. Mirror is high quality silver coated. All mirror and glass panels are safety laminated to pass BS6206, and Class 2B2 BSEN 12600. This ensures that you cannot fall through our glass or mirror panels, and if they were to break, then they crack in safe manner.

FSC Environmental Panels
All our panels are manufactured from FSC certified timber and particle board. FSC is the Forestry Stewardship Council certificate that guarantees our products come from environmentally managed sustainable forests.

Safety
As well as all our glass panels being safety laminated, our bottom wheels also come with an ‘anti jump’ device (shown in red in picture). This locks the wheel in the track to stop doors jumping clear of the track making our product the safest system on the market.

Dimensioned Cross Sectional Drawing

All dimension in mm.  Dimensions are nominal (i.e. subject to manufacturing tolerances)

**Please note the Premium Standard does not use this top track and top guide. Please refer to the made to measure technical specs for a drawing of the Premium top track and wheel mechanism**



Please note this is not an entirely conclusive list of available opening widths.  More width options can be created by mixing different width of doors, and/or  increasing the amount of overlap.
